Hikvision 2.4Ghz 300Mbps 1KM Wireless Bridge | DS-3WF0FA-2N/O
- Built-in 7dBi 2 x 2 MIMO antenna
- 300 Mbps 802.11n wireless bridge
- Up to 1 km wireless transmission distance
Specification
Specifications
Wireless Parameter
Max. Transmission Rate of Air Interface
≤ 300 Mbps
Wireless Standard
IEEE 802.11b/g/n (2 × 2 MIMO 300 Mbps)
Working Frequency Band
2400 MHz~2483.5 MHz
Transmitting Power
17 ± 2 dBm @HT40 MCS7 (Note: Transmitting power may vary with local regulations.)
Receiving Sensitivity
-87 ± 2 dBm @HT40 MCS0
Antenna Gain
7 dBi
Antenna Angle
Beamwidth [3 dB] (65° ± 5°)
Network Parameters
Networking Mode
Point to point: Support up to 8-ch IPC (2MP) in Max. 1 KM distance and Max. 20 Mbps bandwidth;
Point to multi-point: Support up to 4-ch IPC (2MP) in Max. 1 KM distance and Max. 20 Mbps bandwidth within 65° ± 5°, Max. 1 to 4
PTMP connection
Hardware Parameter
Port Numbers
2 × 10/100 Mbps RJ45 ports
LED Indicator
Power indicator, LAN indicator, signal intensity indicator
Reset
Hardware resetting button
Power Supply
12 VDC/1 A Passive PoE
General
Product Dimensions
(W × H × D)
92 mm × 187 mm × 58 mm (3.62” × 7.36” × 2.28”)
Package Dimensions
(W × H × D)
132 mm × 228 mm × 91 mm (5.19" × 8.97" × 3.58")
Net Weight
0.26 kg (0.57 lb)
Gross Weight
0.6 kg (1.32 lb)
Working Temperature
-30 °C to 70 °C (-22 °F to 158 °F)
