Hikvision 8MP AcuSense Fixed Bullet Network Camera | DS-2CD2083G2-I

Image Sensor

1/2.8" Progressive Scan CMOS

Min. Illumination

Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR

Wide Dynamic Range

120 dB

Day & Night

IR cut filter

Angle Adjustment

Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°

Lens Type

Fixed focal lens, 2.8, 4, and 6 mm optional

Focal Length & FOV

2.8 mm, horizontal FOV 107°, vertical FOV 57°, diagonal FOV 128°

4 mm, horizontal FOV 87°, vertical FOV 46°, diagonal FOV 105°

6 mm, horizontal FOV 54°, vertical FOV 29°, diagonal FOV 63 °

DORI

2.8 mm: D: 88 m, O: 35 m, R: 17 m, I: 9 m4 mm: D: 108 m, O: 43 m, R: 22 m, I: 11 m6 mm: D: 177 m, O: 70 m, R: 35 m, I: 18 m

IR Range

Up to 40 m

Max. Resolution

3840 × 2160

Main Stream

50 Hz: 20 fps (3840 × 2160) 25 fps (3200 × 1800, 2688 × 1520, 1920 × 1080, 1280 × 720)60 Hz: 20 fps (3840 × 2160) 30 fps (3200 × 1800, 2688 × 1 520, 1920 × 1080, 1280 × 720)

Material

Aluminum Alloy BodyIR cover: Plastic

Dimensions

Ø 70 mm × 161.7 mm (Ø 2.8" × 6.4")

Weight

Approx. 495 g (1.1 lb.)

Protection

IP67 (IEC 60529-2013)
